Description
ASUS Tianxuan 5 Pro FA607P 2024 (R9-7940HX + RTX 4070) – Ryzen 9 7940HX · RTX 4070 (8 GB GDDR6, 140 W) · 16 GB DDR5 5600 MHz · 1 TB PCIe 4.0 SSD · 16″ 2.5K 165 Hz Display
| Model | ASUS Tianxuan 5 Pro FA607P (2024 Edition) |
| Processor (CPU) | AMD Ryzen 9 7940HX (Zen 4 Architecture, 5 nm, 16 Cores / 32 Threads, up to 5.2 GHz Max Boost, 80 MB Cache, 90 W TDP) |
| Graphics (GPU) | NVIDIA GeForce RTX 4070 Laptop GPU (8 GB GDDR6, 140 W TGP, DLSS 3.5, Ray Tracing, Tensor Core AI Acceleration, NVIDIA Studio Certified) |
| GPU Architecture | Ada Lovelace Architecture with 8th Gen NVENC & 5th Gen NVDEC (Supports AV1 Encode/Decode) |
| AI Acceleration | NVIDIA RTX AI Engine – Up to 233 TOPS AI Compute Performance |
| RAM | 16 GB DDR5 5600 MHz (1 × 16 GB Module, Dual Slot, Upgradeable up to 64 GB) |
| Storage | 1 TB PCIe 4.0 NVMe SSD (Dual M.2 Slots, Supports RAID 0 and Expansion) |
| Display Size | 16-inch IPS-level Panel |
| Resolution | 2.5 K (2560 × 1600) 16:10 Aspect Ratio |
| Refresh Rate | 165 Hz |
| Response Time | 3 ms |
| Brightness | 400 nits |
| Color Accuracy | 100 % sRGB Color Gamut, DC Dimming (Flicker-Free) |
| Display Features | NVIDIA G-SYNC Support, 90 % Screen-to-Body Ratio |
| Cooling System | IceCool 2.0 Thermal System with Dual Arc Flow Fans (84 Blade Design, Quad Exhaust + Five Heat Pipes, CoolZone Keyboard) |
| Airflow Performance | +13 % Increased Airflow, Smart AI Noise Control |
| Total Thermal Power (TPP) | Up to 170–180 W (Turbo Mode: CPU 90 W + GPU 115–140 W) |
| Performance Modes | Silent / Performance / Turbo (FN + F5 Shortcut) |
| Keyboard | Full-size RGB Shadow Blade Keyboard with AURA SYNC, 1.7 mm Key Travel, Mini LED Backlight, Overstroke Tech, 4 Dedicated Shortcut Keys, Numeric Keypad |
| Touchpad | Large Precision Glass Touchpad with 240 Hz Sampling Rate |
| Audio System | Dual Speakers with Dolby Atmos & Hi-Res Audio Certification + Dual AI Noise-Cancelling Microphones |
| Webcam | FHD + IR Dual Camera with Windows Hello Face Recognition |
| Battery | 90 Wh Lithium-Ion Battery |
| Charging | 100 W USB-C Power Delivery (PD) Fast Charging – 50 % in ~30 Minutes |
| Power Modes | Integrated GPU / Hybrid / Discrete GPU Mode (Switch via Armoury Crate or NVIDIA Advanced Optimus) |
| Ports & Connectivity | – 2 × USB-A 3.2 Gen 1 (10 Gbps) – 2 × USB-C (10 Gbps, DP 1.4 + 100 W PD + G-SYNC Support) – 1 × HDMI 2.1 FRL (8K @ 60 Hz / 4K @ 120 Hz) – 1 × RJ-45 Ethernet Port – 1 × 3.5 mm Audio Combo Jack – Security Lock Slot |
| Wireless | Wi-Fi 6E + Bluetooth 5.3 |
| Build Material | Metal Chassis (Aluminum-Alloy) with Asymmetric Cooling Vent Design |
| Color Options | Eclipse Gray / Phantom Teal |
| Dimensions & Weight | 355 × 252 × 28 mm • Weight: ≈ 2.2 kg |
| Hinge Design | 180° Lay-Flat Hinge |
| Software Features | Armoury Crate (Control Center, Fan Profiles, Lighting & Performance Settings), MUX Switch + Advanced Optimus, Game Visual Modes, TX Boost AI Acceleration |
| Operating System | Windows 11 Home / Pro (64-bit) |
| Certifications | Dolby Atmos / Hi-Res Audio / NVIDIA Studio Certified |
| Warranty Information |
1-Year International Warranty /2 Years Manufacturer’s Official Warranty. |
